Major Repair Kit with Oil Pump Rotor 20040025KIT
Major Service Kit includes; oil pump rotor, Vanes, hardware, gaskets, demister filters, springs, O-rings, seals, Valves, spacers, and other components for a major overhaul
General product classifications
Brand | Leybold |
Family | Trivac |
Pump models | D1.2E |
Category | Repair Kits |
Subcategory | Major Kit |
Country of origin | US |
Manual page | LEYBOLD-69 |
Part number alternatives | 20040025KITNR 20040025MINOR |
PART NUMBER | DESCRIPTION | QUANTITY |
---|---|---|
490023 | Compression Spring, Leybold, Trivac, Part# 490023 | 1 |
490022 | Compression Spring, Leybold, Trivac, D2.5E, D5E, Part# 490022 | 1 |
300044 | Sight Glass Gasket, Leybold, Trivac, D2.5E, D5E, Part# 300044 | 1 |
300046 | ring Gasket, Viton-Leybold Trivac, Part# 300046 | 2 |
300047 | Flat Gasket, Leybold, Trivac, D2.5E, D1.2E, Part# 300047 | 1 |
300049 | Oil Box Gasket, Leybold, Trivac, D2.5E, D1.2E, Part# 300049 | 1 |
310047 | Shaft Seal, Lip - with Dust Lip-Leybold Trivac, Part# 310047 | 1 |
310048 | Shaft Seal, Lip - without Dust Lip, Leybold, Trivac, D2. 5E, D1. 2E, Part# 310048 | 1 |
320117 | O-ring, 92 x 3 mm - Viton, Part# 320117 | 1 |
360051 | Coupler, Sleeve, Viton-Leybold Trivac, Part# 360051 | 2 |
400061 | Screw, M5 x 65 mm, Leybold, Trivac, Part# 400061 | 2 |
490024 | Compression Spring, Vane, Leybold, Trivac, D2.5E, D1.2E, Part# 490024 | 2 |
580032 | Valve, Nib, Viton - Leybold, Trivac, Part# 580032 | 1 |
580033 | Tandem Valve, Steel, Leybold, Trivac, D2.5E, D5E, Part# 580033 | 1 |
580034 | Bracket Valve, Leybold, Trivac, D2.5E, D1.2E, Part# 580034 | 1 |
400063 | Screw, M5 x 20 mm, Leybold, Trivac, Part# 400063 | 4 |
400064 | Screw, M5 x 10 mm, Leybold, Trivac, Part# 400064 | 2 |
P23955165 | Leybold Gasket, Viton, Part# P23955165 | 2 |
450031 | Guide Pin, Vane, Stainless Steel-Leybold Trivac, Part# 450031 | 1 |
490020 | Spring, Restrictor Retainer, Leybold, Trivac, D2.5E, D5E, Part# 490020 | 1 |
490021 | Compression Spring - Leybold, Trivac, Part# 490021 | 1 |
200090 | Oil pump Rotor, Leybold, Trivac, D1.2E, D2.5E, Part# 200090 | 1 |
230046G | Vane, 1st Stage - GX, Leybold, Trivac, Part# 230046G | 2 |
230047G | Vane, 2nd Stage GX, Leybold, Trivac, D2.5E, D1.2E, Part# 230047G | 2 |
23963115 | O-ring, 38 x 3 mm - Viton, Part# 23963115 | 1 |
PL23970120 | O-ring, 37 x 3 mm - Viton, Part# PL23970120 | 1 |
PL23973146 | Seal, Float, Leybold, Trivac, Part# PL23973146 | 1 |
450030 | Guide Pin, Vane, Stainless Steel- Leybold Trivac, Part# 450030 | 1 |
440023 | Spacer ring, Steel, 35 x 29 x 1 mm, Leybold, Trivac, Part# 440023 | 1 |
420033 | Flat Washer, Leybold, Trivac, Sogevac, Part# 420033 | 6 |
PL40050135 | Valve, Leybold, Trivac, D2.5E, D5E, Part# PL40050135 | 1 |
400065 | Screw, M5 x 6 mm, Leybold, Trivac, Part# 400065 | 1 |
720010 | Leybold Demister Filter, Part# 720010 | 1 |
580038 | Stopper Valve, Steel, Leybold, Trivac, D1.2E, D2.5E, Part# 580038 | 1 |
580037 | Valve Holder, Leybold, Trivac, Part# 580037 | 1 |
580036 | Valve Spacer - Leybold, Trivac, Part# 580036 | 1 |
