Major Repair Kit 36501814XL
Major Repair Kit includes; seals, coupling element, O-rings, gaskets, Vanes, springs, and bearings for a major overhaul
General product classifications
Brand | Edwards |
Family | E1/E2M |
Pump models | E2M80 |
Category | Repair Kits |
Subcategory | Major Kit |
Country of origin | US |
Manual page | EDWARDS-50 |
Part number alternatives | 23E-E2M80-V |
PART NUMBER | DESCRIPTION | QUANTITY |
---|---|---|
02125020 | O-Ring, 18.64 x 3.53 mm - Viton | 1 |
02125044 | O-Ring, 46.99 x 5.33 - Buna | 2 |
02125115 | O-Ring, 4.42 x 2.62 mm - Buna | 2 |
02124119 | O-Ring, 12.42 x 1.78 mm - Viton | 1 |
02120101 | O-Ring, 159.5 x 3 mm - Buna | 1 |
02120082 | O-Ring, Buna | 1 |
20402087XL | Vane, 2nd Stage - X-Lon | 2 |
20402418XL | Vane, Oil Pump - X-Lon - Edwards E2M40 / E2M80 | 2 |
20402089XL | Vane, 1st Stage - X-Lon | 2 |
20404012 | Edwards Bearing, Part# 20404012 | 2 |
22304041 | Edwards Oil Filter, Nonazide Part# 22304041 | 1 |
29201006 | Sight Glass | 1 |
02120057 | O-Ring, 61.6 x 2.4 mm - Buna | 1 |
02120031 | O-Ring, 9.6 x 2.4 mm - Buna | 1 |
02120027 | O-Ring, 5.23 x 2.62 mm - Buna | 1 |
02109094 | Edwards Shaft Seal, Viton, Part# 02109094 | 2 |
02109064 | Edwards Shaft Seal, Viton, Part# 02109064 | 1 |
02104014 | Dowty Seal | 1 |
02104002 | Dowty Seal | 1 |
36501024 | Edwards Drive Member, Part# 36501024 | 2 |
27102024 | Spring | 1 |
27804004 | Valve Spacer | 6 |
27159618 | Oil Box Gasket | 1 |
27159541 | Exhaust Valve, LV, Viton | 1 |
27159509 | Exhaust Valve, Viton | 1 |
21071033 | Edwards Coupling Element, Part# 21071033 | 1 |
22305035 | Inlet Filter Assembly | 1 |
22305050 | Oil Filter Assembly | 1 |
22426004 | C-Clip | 1 |
27102013 | Spring, Stainless Steel | 1 |
27159428 | Gasket, Viton | 1 |
01403030 | Filter Seal, Buna | 1 |
19201007 | Ballast Piston Assembly | 1 |
25904601 | Ballast Valve | 1 |
02104008 | Dowty Seal, Buna | 1 |
02104001 | Dowty Seal | 2 |
02125116 | O-Ring, 7.92 x 2.6mm - Buna | 5 |
02126011 | O-Ring, 10.77 x 2.62 mm - Viton | 1 |
218990201 | Waved Washer | 1 |
22305041 | Felt Ballast Filter | 2 |
26501012 | Edwards Sight Glass Seal, Part# 26501012 | 1 |
7159415 | Seal, Viton | 1 |
27159504 | Exhaust Valve, LV, Viton | 1 |
