Major Repair Kit with X-Lon Vanes - Edwards E2M28 / E2M30 37301800XL
For complete kit content details see bill of materials below
General product classifications
| Brand | Edwards |
| Family | E1/E2M |
| Pump models | E2M28 E2M30 |
| Category | Repair Kits |
| Subcategory | Maintenance Kits |
| Country of origin | US |
| Manual page | EDWARDS-49 |
| Part number alternatives | 23E-E2M30-V |
| PART NUMBER | DESCRIPTION | QUANTITY |
|---|---|---|
| 27159532 | Gasket, Edwards, E1/E2M, Part# 27159532 | 1 |
| 27159635 | Oil Box Gasket, Edwards, E1/E2M, Part# 27159635 | 1 |
| 27159638 | Sight Glass Gasket-Edwards E1/E2M, Part# 27159638 | 1 |
| 02122083 | O-ring, 69.5 x 3 mm - Viton, Part# 2122083 | 1 |
| 02125300 | O-ring, 107.6 x 2.6 mm - Buna, Part# 2125300 | 1 |
| H02122012 | O-Ring FKM GP 14.1ID X 1.6SEC | 1 |
| A11301045 | Ballast Valve PTFE | 1 |
| 20402157XL | Vane, Oil pump - X - Lon - Edwards, E1/E2M, Part# 20402157XL | 1 |
| 20402155XL | Vane, 2nd Stage - X - Lon, Edwards, E1/E2M, E2M28, E2M30 Part# 20402155XL | 2 |
| 20402153XL | Vane, 1st Stage X - Lon, Edwards, E1/E2M, E2M28, E2M30, Part# 20402153XL | 2 |
| 02120078 | O-ring, 44.5 X 3 mm - Buna, Part# 02120078 | 2 |
| A20404011 | Roller Bearing | 2 |
| A01403030 | Oil Filter Seal | 2 |
| A22305008 | Filter Assembly E2M 18/28 | 1 |
| 27102032 | Distributor Spring - Edwards, E1/E2M, Part# 27102032 | 1 |
| 27102033 | Valve Spring, E1/E2M, Part# 27102033 | 2 |
| 29203003 | Blade Spring Pin, Edwards, E1/E2M, Part# 29203003 | 2 |
| 02125026 | O-ring, 28.17 x 3.53 mm - Viton, Part# 2125026 | 2 |
| P212081133 | C-Clip, Edwards, E1/E2M, Part# P212081133 | 1 |
| 00906077 | Spring, Stainless Steel, Edwards, E1/E2M, Part# 906077 | 2 |
| 02104012 | Dowty Seal-Edwards E1/E2M, Part# 02104012 | 2 |
| 02104030 | Dowty Seal, Edwards, E1/E2M, Part# 2104030 | 1 |
| 02109064 | Edwards Shaft Seal, Viton, Part# 02109064 | 1 |
| 02109094 | Edwards Shaft Seal, Viton, Part# 02109094 | 2 |
| 02120028 | O-ring, 6.6 x 2.4 mm - Buna, Part# 2120028 | 9 |
| 02120068 | O-ring, 30 X 3 mm- Buna, Part# 2120068 | 1 |
| 02120072 | O-ring, 35.5 X 3 mm - Buna, Part# 02120072 | 1 |
| 02120085 | O-ring, 79.5 X 3 mm - Buna, Part# 2120085 | 1 |
| 02120087 | O-ring, 89.2 X 3 mm - Buna, Part# 2120087 | 1 |
| 02122009 | O-ring, 11.1 x 1.6 mm - Buna, Part# 02122009 | 2 |
| 02122035 | O-ring, 13.6 x 2.4 mm - Viton, Part# 2122035 | 1 |
| 02122037 | O-ring, 15.3 x 2.4 mm - Viton, Part# 02122037 | 2 |
| 02122108 | O-ring, 194.5 x 3 mm - Viton, Part# 2122108 | 1 |
| 02126116 | O-ring, 7.59 x 2.62 mm - Viton, Part# 02126116 | 2 |
| 02308043 | Gas Ballast Filter-Edwards E1/E2M, Part# 02308043 | 2 |
| 02308044 | Gas Ballast Filter-Edwards E1/E2M, Part# 2308044 | 2 |
| 218990201 | Waved Washer | 1 |
| 22302017 | Felt Pad, Edwards, E1/E2M, E1M18, E2M18, E2M28, E2M30 Part# 22302017. | 1 |
| 26501029 | Valve Pad, Edwards, E1/E2M, Part# 26501029 | 3 |
| 26501032 | Coupling Element, Edwards, Welch, E1/E2M, CRVpro, Part# 26501032 | 1 |
| 27102030 | Exhaust Valve Spring - Edwards, E1/E2M, Part# 27102030 | 1 |
| 27102041 | Spring, Edwards, E1/E2M, E2M28, E2M30, Part# 27102041 | 1 |
| 27159430 | Distributor, Rubber, Edwards, E1/E2M, E1M18, E2M18, Part# 27159430 | 1 |
| 27159530 | Sight Glass Gasket-Edwards E1/E2M, Part# 27159530 | 1 |
