Product Gallery Major Repair Kit with X-Lon Vanes, 103909XL

Accepted at Checkout

Last 5 Products Reviewed

Major Repair Kit with X-Lon Vanes, 103909XL

Price Each

Quantity

Price:

$ 385.95

 $ 539.50
Quantity:
Add to Cart

Major Repair Kits with X-Lon Vanes includes; coupling, element, c-clips, O-rings, gaskets, washers, shaft seals, Vanes, springs, and sight glass for major overhaul. Used on Pump Models 2021I

General product classifications

Brand Alcatel-Adixen
Family Pascal
Pump models 2021I
Category Repair Kits
Subcategory Major Kit
Country of origin US
Manual page ALCATEL-10
Part number alternatives 23A-2021I-V





PART NUMBER DESCRIPTION QUANTITY
71161 C-Clip 1
720007 Felt Pad 1
73452 Wave Washer, M4 4
73453 Wave Washer, M5 1
73460 Wave Washer, M6 19
79148 O-Ring,Viton,165 X 3 MM 1
79506 O-Ring,Viton,213 X 3 MM 1
79513 O-Ring,Viton,90 X 2 MM 4
79537 O-Ring,Viton,7.5 X 1.5 MM 1
320067 O-Ring,Viton,63.09 X 3.53 MM 1
65784 Sight Glass 1
79509 O-Ring,Viton,28 X 3 MM 1
490060 Anti-Suckback Spring 1
380029 Anti-Suckback Device, Viton 1
230044XL Vane, Oil Pump - X-Lon 1
65756XL Vane, 2nd Stage - X-Lon 2
65759XL Vane, 1st Stage - X-Lon 2
250010 Shouldering Ring, Coated 1
320035 O-Ring,Viton,17.12 X 2.62MM 3
71040 Centering Pin 4
65799 Spring 1
65797 Spring 1
65791 Valve 1
580031 Gas Ballast Sleeve 1
53040 Vane Spring 8
52553 Elastic Coupler 1
52541 Valve Spring 4
420029 Flat Washer, Steel 2
390007 Valve Disk, Viton 4
340023 Anti-Suckback Nib, Viton 1
320109 O-Ring,Viton,33 X 2.5 MM 1
82604 Plastic Drain Plug 3
71067 Shaft Key 1
84646 Waved Washer 1
82063 Shaft Seal, Viton 4
82025 O-Ring,Viton,29.3 X 3.6 MM 4
82014 O-Ring,Viton,34.1 X 3.6 MM 1
82007 O-Ring,Viton,10.77 X 2.62 MM 1
82004 O-Ring,Viton,5.7 X 1.9 MM 3
320036 O-Ring,Viton,12.1 X 2.7 MM 1
